1460~1620 nm 8channel coarse wavelength division multiplexers CWDM Mux&DeMux SMF-28e
Product Description
Coarse Wavelength Division Multiplexers (CWDMs) demonstrate low loss and reliable performance. These devices show broad passbands and high isolation, making them ideal for operation with inexpensive, uncooled lasers. They feature up to 4 or 8 low dispersion channels, thereby enabling high capacity, low cost products for the CATV and metro/access markets.
Easily customizable, CWDMs can be configured from a standard list of packaging and connector options
Features
- Low insertion loss
- High channel isolation
- Low polarization dependent loss
- Exceptional reliability and stability
Applications
- Access networks
- Metro WDM systems
- Enterprise networks
specification
| Item | Unit | Parameters | Note |
| Wavelength range | nm | 1460~1620 | 1260~1620 | |
| Channel centers (ITU or ITU+1) | nm | 1470/1490…1610 or 1471/1491…1611 | 1270/1290…1610 or 1271/1291…1611 | |
| Channels | ch | 4 | 8 | 4 | 8 | |
| Passband | nm | ≥+/-7 | |
| Passband ripple | dB | ≤0.5 | |
| Channel insertion loss | dB | 2.0 | 2.8 | 2.0 | 2.8 | |
| Optional express insertion loss | dB | 1.8 | 2.6 | 1.8 | 2.6 | |
| Isolation (adjacent channel) | dB | ≥30 | |
| Isolation (non-adjacent channel) | dB | ≥45 | |
| Polarization dependent loss | dB | ≤0.2 | |
| Polarization mode dispersion | ps | ≤0.2 | |
| Directivity | dB | ≥50 | |
| Return loss | dB | ≥45 | |
| Optical power handling | mW | ≤500 | |
| Operating temperature range | 0C | -5 to 70 0C | |
| Storage temperature range | 0C | -40 to +85 0C | |
| Fiber type | | SMF-28e | |
| Connector Type | | | |
| Package dimensions (L x W x H) | mm | 100 x 80 x 10 | ABS |
dimension drawing (mm)
spectral plot(dB)
ordering information
package&shipping
According to the customer's requirement
The quotation of this product does not bear transportation costs
We can provide packing according to customer's requirement, quantity, weight and volume.
We can provide customized products for customers. We only need to provide requirements, samples, specifications, drawings, etc.
